Structural 8mm dowel construction. ¾” thick nailer for high strength mounting to wall.
¾” thick front and rear spreaders for added cabinet stability. Upper and tall cabinets have a solid ¾” thick top. Sink bases will have a wide front and rear vertical member. Intermediate spreaders are located below drawers for added rigidity.
Complete 4 sided drawer construction with captured bottom; thermofused laminate (TFL) panels; separate, removable drawer front. Other drawer box options are available.
100# full extension, ball bearing, side mount drawer slides are standard, and allow for full access to drawer space. There are many other drawer slide options available.
Concealed, six way adjustable hinges to maintain equal door reveal spacing. 110 degree opening standard, with optional 120 degree opening and 5 knuckle institutional hinges available.
Exterior clad in durable high pressure laminate or thermofused laminate (TFL). Balanced panels with high strength, high density industrial core material.
Thermofused laminate (TFL) interiors are easy to clean and non-porous. Standard in white, with matching open interiors, or available in many color and woodgrain options. Steel shelf support pins, adjustable on 32mm (1-1/4”) centers.
Matching high quality PVC edge banding available in standard .5mm thickness or optional 3mm thickness (3mm color match subject to availability).
Integral toe kick allows direct sidewall transfer of all loads to floor. Toe kick is unfinished for application of room base or optional base cover.
¼” thick backs are captured in cabinet member grooves. Mechanical fastening adds lateral strength to the case.
Better Case Construction
- Quality Blum Soft Close Hinges
- 100 lb. Rated Drawer
- 8mm Dowel Construction
- 3/4” Material
- Balance Laminated Panels
- Wide Variety of Colors
- Customizable Sizes
Better Warranty
We back up our Quest standard products with a five year warranty.
